3M 10024 Scotchlok Copper Standard Barrel Connector, Up To 35 Kv, 1000 Kcmil, White
Product Specifications
UPC: 05400712931
Barrel Type: STANDARD BARREL
Length: 3.88 INCH
Length In Inch: 3.88
Inner Diameter: 1.173 INCH
Outer Diameter: 1.5 INCH
Body Material: COPPER
Approval: UL 486-A, UL 486-B, CSA
Additional Information: PACKAGING QUANTITY 3 PER CASE; APPLICATION INDOOR/OUTDOOR
Catalog Number: 10024
Brand Name: Scotchlok[T]
Model: 10000
Type: CENTER WIRE STOP
Voltage Rating: 35 KV
Conductor Size: 1000 KCMIL
Conductor Material: COPPER
Color Code: WHITE
Catalog Description: THEY ARE DESIGNED TO CONNECT COPPER CONDUCTORS. EACH CONNECTOR IS ELECTRO-TIN PLATED TO RESIST ELECTROLYTIC CORROSION. THEY ARE INSTALLED USING STANDARD INDUSTRY TOOLING. CHAMFERED ENDS AND AN INTEGRAL CENTER CABLE STOP ENSURE SIMPLICITY AND EASE OF CONDUCTOR INSERTION.
Category: Large Terminals & Connectors
Full Technical Description: Center Wire Stop Type; 3.88 Inch; 3.88 Length in Inch; 1.173 Inch Inner Diameter; 1.5 Inch Outer Diameter; Copper Conductor Material; UL 486-A, UL 486-B, CSA Approval; 35 kV Voltage Rating; Copper Body Material; 1000 kcmil Conductor Size; White Color Code; Standard Barrel Barrel Type; SCOTCHLOK[T] Brand; Packaging Quantity 3 Per Case; Application Indoor/Outdoor; 10000 Model
