3M 20005 Scotchlok Aluminum Connector, Up To 35 Kv, 1/0 Awg, Tan

Overview

3M 20005 Scotchlok Aluminum Connector, Up To 35 Kv, 1/0 Awg, Tan

Product Specifications

• UPC: 05400713277
• Length: 2.12 Inch
• Inner Diameter: 0.39 Inch
• Outer Diameter: 0.64 Inch
• Body Material: Electro Tin Plated Aluminum
• Approval: UL
• Additional Information: RoHS Compliant; Used On 5420/5461/5450 Series Splice Kit
• Catalog Number: 20005
• Brand Name: Scotchlok[TM]
• Model: 20000
• Voltage Rating: 35 Kilovolt
• Conductor Size: 1/0 AWG
• Conductor Material: Aluminum/Copper
• Color Code: Tan
• Barrel Type: Standard
• Catalog Description: THE 3M SCOTCHLOK CONNECTORS 20000 SERIES CAN BE USED WITH EITHER COPPER OR ALUMINUM CONDUCTORS. THESE ALUMINUM CONNECTORS FEATURE COLOR CODED END CAPS FOR IDENTIFICATION. CONTACT AID PROVIDED IN CONNECTOR IS COMPATIBLE WITH POLY/EPR INSULATIONS. EACH CONNECTOR IS ELECTRO TIN PLATED TO RESIST ELECTROLYTIC CORROSION, AND HAVE A SOLID CENTER STOP. (UL 486B LISTED)
• Category: Large Terminals & Connectors
• Full Technical Description: 2.12 Inch; 0.39 Inch Inner Diameter; 0.64 Inch Outer Diameter; Aluminum/Copper Conductor Material; UL Approval; 35 Kilovolt Voltage Rating; Electro Tin Plated Aluminum Body Material; 1/0 AWG Conductor Size; Tan Color Code; Standard Barrel Type; RoHS Compliant; Used on 5420/5461/5450 Series Splice Kit; 20000 Model
• Made In Usa: Yes
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Splice
• Unspsc: 27121707
• UPC 12 Digit: 054007132776
• SKU Name: 3m 20005
