3M 31060 Scotchlok Copper 1-Hole Long Barrel Lug, Up To 35 Kv, 400 Kcmil, Blue

Overview

3M 31060 Scotchlok Copper 1-Hole Long Barrel Lug, Up To 35 Kv, 400 Kcmil, Blue

Product Specifications

• UPC: 05400711978
• Pad Size: 1.34 Inch L x 1.41 Inch W
• Number Of Pad Holes: 1
• Stud Size: 1/2 Inch
• Color: Blue
• Material: Tin Plated Copper
• Overall Length: 4.16 Inch
• Approval: UL, CSA
• Additional Information: Inside Diameter 0.76 Inch; Outside Diameter 0.95 Inch; Used On Copper Conductor; Application Indoor, Outdoor; Operating Temperature 105 Deg C
• Catalog Number: 31060
• Brand Name: Scotchlok[TM]
• Model: 31000
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 400 KCMIL
• Barrel Type: Long
• Barrel Length: 2 Inch
• Catalog Description: 3M SCOTCHLOK 31000 1 HOLE COMPRESSION LUG IS FOR USE WITH COPPER CONDUCTORS ONLY. THE LONG BARREL ENSURES A SECURE FIT. SEAMLESS COPPER CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND AN ELECTRO TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Copper Material; Blue Color; 4.16 Inch Overall Length; 2 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 400 kcmil Conductor Size; 1/2 Inch Stud Size; 1.34 Inch L X 1.41 Inch W Pad Size; 1 Pad Hole(S); Long Barrel Type; Inside Diameter 0.76 Inch; Outside Diameter 0.95 Inch; Used on Copper Conductor; Application Indoor, Outdoor; Operating Temperature 105 Deg C; 31000 Model
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Lug
• Unspsc: 27121707
• UPC 12 Digit: 054007119784
• SKU Name: 3m 31060
