3M 40137 Scotchlok Aluminum 2-Hole Lug, Up To 35 Kv, 2/0 Awg, Olive
Product Specifications
UPC: 05400713616
Pad Size: 3.25 Inch L x 0.94 Inch W
Number Of Pad Holes: 2
Pad Hole Spacing: 1.75 Inch
Stud Size: 1/2 Inch
Color: Olive
Die Index: 297
Material: Aluminum
Overall Length: 5.5 Inch
Approval: UL
Additional Information: Inside Diameter 0.44 Inch; Outside Diameter 0.68 Inch; Used On Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C
Catalog Number: 40137
Brand Name: Scotchlok[TM]
Model: 40000
Voltage Rating: 35 KV
Conductor Material: Aluminum/Copper
Conductor Size: 2/0 AWG
Barrel Type: Standard
Barrel Length: 1.5 Inch
Catalog Description: 3M SCOTCHLOK 40100 2 HOLE COMPRESSION LUG IS SUITABLE FOR USE WITH COPPER OR ALUMINUM CONDUCTORS. THE LUG HAS A STANDARD BARREL THAT ENSURES A SECURE FIT. ALUMINUM CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND AN ELECTRO TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
Category: Large Terminals & Connectors
Full Technical Description: Aluminum Material; Olive Color; 5.5 Inch Overall Length; 1.5 Inch Barrel Length; Aluminum/Copper Conductor Material; UL Approval; 35 kV Voltage Rating; 2/0 AWG Conductor Size; 1/2 Inch Stud Size; 297 Die Index; 3.25 Inch L X 0.94 Inch W Pad Size; 2 Pad Hole(S); 1.75 Inch Pad Hole Spacing; Standard Barrel Type; Inside Diameter 0.44 Inch; Outside Diameter 0.68 Inch; Used on Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C; 40000 Model
