3M 40141 Scotchlok Aluminum 2-Hole Lug, Up To 35 Kv, 3/0 Awg, Ruby

Overview

3M 40141 Scotchlok Aluminum 2-Hole Lug, Up To 35 Kv, 3/0 Awg, Ruby

Product Specifications

• UPC: 05400713624
• Pad Size: 3.25 Inch L x 1.06 Inch W
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1.75 Inch
• Stud Size: 1/2 Inch
• Color: Ruby
• Die Index: 167/467
• Material: Aluminum
• Overall Length: 5.5 Inch
• Approval: UL
• Additional Information: Inside Diameter 0.48 Inch; Outside Diameter 0.76 Inch; Used On Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C
• Catalog Number: 40141
• Brand Name: Scotchlok[TM]
• Model: 40000
• Voltage Rating: 35 KV
• Conductor Material: Aluminum/Copper
• Conductor Size: 3/0 AWG
• Barrel Type: Standard
• Barrel Length: 1.5 Inch
• Catalog Description: 3M SCOTCHLOK 40100 2 HOLE COMPRESSION LUG IS SUITABLE FOR USE WITH COPPER OR ALUMINUM CONDUCTORS. THE LUG HAS A STANDARD BARREL THAT ENSURES A SECURE FIT. ALUMINUM CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND AN ELECTRO TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
• Category: Large Terminals & Connectors
• Full Technical Description: Aluminum Material; Ruby Color; 5.5 Inch Overall Length; 1.5 Inch Barrel Length; Aluminum/Copper Conductor Material; UL Approval; 35 kV Voltage Rating; 3/0 AWG Conductor Size; 1/2 Inch Stud Size; 167/467 Die Index; 3.25 Inch L X 1.06 Inch W Pad Size; 2 Pad Hole(S); 1.75 Inch Pad Hole Spacing; Standard Barrel Type; Inside Diameter 0.48 Inch; Outside Diameter 0.76 Inch; Used on Aluminum/Copper Conductor; Application Indoor, Outdoor; Operating Temperature 90 Deg C; 40000 Model
• Made In Usa: Yes
• Manufacturer: 3M ELECTRICAL MARKET ELECTRICAL PRODUCTS
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Lug
• Unspsc: 27121707
• UPC 12 Digit: 054007136248
• SKU Name: 3m 40141
