3M 40149 Scotchlok Aluminum 2-Hole Lug, Up To 35 Kv, 250 Kcmil, Red

Overview

3M 40149 Scotchlok Aluminum 2-Hole Lug, Up To 35 Kv, 250 Kcmil, Red

Product Specifications

• UPC: 05400713640
• Pad Size: 3.38 Inch Length x 1.25 Inch Width
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1.75 Inch
• Stud Size: 1/2 Inch
• Color: Red
• Material: High Conductivity Aluminum
• Overall Length: 6 Inch
• Approval: UL
• Additional Information: RoHS Compliant; Outer Diameter 0.906 Inch; Used On Aluminum/Copper Conductor; Application Indoor/Outdoor
• Catalog Number: 40149
• Brand Name: Scotchlok[TM]
• Model: 40000
• Voltage Rating: 35 Kilovolt
• Conductor Material: Aluminum
• Conductor Size: 250 KCMIL
• Barrel Type: Standard
• Barrel Length: 1.94 Inch
• Catalog Description: 3M SCOTCHLOK 40100 2 HOLE COMPRESSION LUG IS SUITABLE FOR USE WITH COPPER OR ALUMINUM CONDUCTORS. THE LUG HAS A STANDARD BARREL THAT ENSURES A SECURE FIT. ALUMINUM CONSTRUCTION OFFERS HIGH CONDUCTIVITY AND AN ELECTRO TIN PLATED FINISH RESISTS CORROSION. IT IS RATED FOR 35 KV VOLTAGE APPLICATIONS.
• Category: Large Terminals & Connectors
• Full Technical Description: High Conductivity Aluminum Material; Red Color; 6 Inch Overall Length; 1.94 Inch Barrel Length; Aluminum Conductor Material; UL Approval; 35 Kilovolt Voltage Rating; 250 kcmil Conductor Size; 1/2 Inch Stud Size; 3.38 Inch Length X 1.25 Inch Width Pad Size; 2 Pad Hole(S); 1.75 Inch Pad Hole Spacing; Standard Barrel Type; RoHS Compliant; Outer Diameter 0.906 Inch; Used on Aluminum/Copper Conductor; Application Indoor/Outdoor; 40000 Model
• Made In Usa: Yes
• Manufacturer: 3M ELECTRICAL MARKET ELECTRICAL PRODUCTS
• Manufacturer Brand: 3M Electrical Products
• Sub Category: Compression Cable Lug
• Unspsc: 27121707
• UPC 12 Digit: 054007136408
• SKU Name: 3m 40149
