3M 7622-T-95 Cold Shrink QT-III Termination Kit, Tape/Wire/Unishield Shielding, 5-8.7 Kv, Insulation Od 0.64-1.08

Overview

3M 7622-T-95 Cold Shrink QT-III Termination Kit, Tape/Wire/Unishield Shielding, 5-8.7 Kv, Insulation Od 0.64-1.08

Product Specifications

• UPC: 05112857483
• Insulator Type: Tubular
• Cable Insulation Outer Diameter: 0.64 to 1.08 Inch
• Connector Type: Lug
• Conductor Size: 4/0 AWG to 400 KCMIL (5 Kilovolt), 3/0 AWG to 300 KCMIL (8 Kilovolt)
• Contents: (3) Hi-K Silicone Rubber Termination, (3) Pre-Formed Ground Braid, (3) Constant Force Spring, (6) Mastic Seal Strip, (1) Cable Preparation Kit, (3) Copper Foil Shielding Tape Strip, (1) Instruction Sheet
• Additional Information: Installed Length 8.5 Inch; Number of Conductors 1; Applicable Standard IEEE
• Catalog Number: 7622-T-95
• Model: 7620-T
• Type: Cold Shrink
• Voltage Rating: 5 to 8.7 Kilovolt
• Bil Rating: 95 Kilovolt
• Cable Type: Tape/Wire Shield, Unishield
• Number Of Terminations: 3
• Insulator Material: Silicone Rubber
• Catalog Description: 3M COLD SHRINK QT-III SILICONE RUBBER TERMINATION KIT 7620-T AND 7690-T SERIES CONTAINS ONE-PIECE, NON-SKIRTED, SILICONE RUBBER TERMINATIONS, MEETS IEEE STANDARD 48 CLASS 1 FOR INDOOR AND WEATHER-PROTECTED APPLICATIONS. THE KITS ARE DESIGNED FOR TERMINATING SOLID DIELECTRIC SHIELDED POWER CABLE RATED 535 KV, WITH TAPE SHIELD, WIRE SHIELD AND UNISHIELD CONSTRUCTIONS.
• Category: Splicing & Terminating Kits
• Full Technical Description: Cold Shrink Type; Tape/Wire Shield, Unishield Cable Type; (3) Hi-K Silicone Rubber Termination, (3) Pre-Formed Ground Braid, (3) Constant Force Spring, (6) Mastic Seal Strip, (1) Cable Preparation Kit, (3) Copper Foil Shielding Tape Strip, (1) Instruction Sheet Contents; Lug Connector Type; 5 to 8.7 Kilovolt Voltage Rating; 4/0 AWG to 400 kcmil (5 Kilovolt), 3/0 AWG to 300 kcmil (8 Kilovolt) Conductor Size; 0.64 to 1.08 Inch Cable Insulation Outer Diameter; 95 Kilovolt BIL Rating; Tubular Insulator Type; Silicone Rubber Insulator Material; 3 Termination(S); Installed Length 8.5 Inch; Number of Conductors 1; Applicable Standard IEEE; 7620-T Model
• Made In Usa: Yes
• Manufacturer: 3M Co.
• Manufacturer Brand: 3M MRO Solutions
• Sub Category: Insulated Indoor Termination Kit
• Unspsc: 39120000
• UPC 12 Digit: 051128574836
• SKU Name: 3m 7622t95
