Additional Information: TERMINAL MATERIAL TIN PLATED ETP COPPER; SIZE 0.8 INCH L X 0.25 INCH W X 0.03 INCH THK; BRAZED SEAM BARREL
Catalog Number: MV14-6R/SK
Brand Name: Scotchlok[T]
Type: STANDARD
Minimum Conductor Size: 16 AWG
Maximum Conductor Size: 14 AWG
Color: BLUE
Insulation Type: VINYL INSULATED
Stud Size: #6
Catalog Description: 3M SCOTCHLOK COLOR-CODED SMALL RING TONGUE TERMINAL ENSURES AN IDEAL FIT WHILE OFFERING RELIABLE AND SAFE PERFORMANCE. THE TERMINAL HAS A VINYL-INSULATED, BRAZED-SEAM BARREL AND WITHSTANDS TEMPERATURES OF -40 TO 221 DEGREES F (-40 TO 105 DEGREES C). ELECTROLYTIC COPPER CONSTRUCTION OFFERS GOOD CONDUCTIVITY AND A TIN-PLATED FINISH RESISTS CORROSION.
Category: Small Terminals & Connectors
Full Technical Description: Standard Type; Blue Color; 16 AWG min. Conductor Size; 14 AWG Max. Conductor Size; UL 486-A, CSA C22.2 Approval; 221 Deg F Temperature Rating; 1000 Per Case Standard Package; #6 Stud Size; Vinyl Insulated Insulation Type; SCOTCHLOK[T] Brand; Terminal Material Tin Plated Etp Copper; Size 0.8 Inch L X 0.25 Inch W X 0.03 Inch Thk; Brazed Seam Barrel
