Appleton 270FSA 3/4" Aluminum Conduit Body Cover

Overview

Appleton 270FSA 3/4" Aluminum Conduit Body Cover

Product Specifications

• UPC: 78138160127
• Used On: Rigid/IMC Conduit Outlet Body
• Additional Information: Application Commercial, Industrial, Hazardous Location; Applicable Standard UL 514A/B, CSA C22.2, NEC, CEC, NEMA FB-1
• Catalog Number: 270FSA
• Brand Name: FM7[TM], Wedge-Lok[TM]
• Type: Clip, Screw
• Form Type: Form 7
• Hub Size: 3/4 Inch
• Enclosure: Class I Div 2
• Material: Cast Aluminum (Cover), Stainless Steel (Screw)
• Finish: Epoxy Powder Coated
• Catalog Description: FM7 WEDGE-LOK BLANK CLIP COVER WITH SCREW, HUB SIZE: 3/4 IN, FORM: 7, MOUNTING: SCREW-IN, MATERIAL: CAST ALUMINUM, FINISH: EPOXY POWDER COAT, STANDARD: UL 514A, UL 514B, UL FILE NUMBER E2527, CSA C22.2 NO. 18.3, CSA 065183, NEMA FB-1, FOR
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Clip Type; Zinc Electroplated Copper-Free Cast Aluminum Material; UL 514A/B, CSA C22.2 Approval; 3/4 Inch Trade Size; Form 7 Form Type; FM7[TM], Wedge-LOK[TM] Brand; Enclosure Rating Class I Div 2, NEMA 3R; Operating Temperature Rating -65 to 302 Deg F; Includes Stainless Steel Screw; Used on Imc/Rigid Conduit; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard Nec/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body Cover
• Unspsc: 39131708
• UPC 12 Digit: 781381601276
• SKU Name: app 270fsa
