Appleton ADR3022 2W-2P Receptacle

Overview

Appleton ADR3022 2W-2P Receptacle

Product Specifications

• UPC: 78138118632
• Grounding Style: 1, Shell
• Door Type: Spring Door, Screw Cap
• Material: Epoxy Powder Coated Copper Free Aluminum
• Grade: Shipping
• Approval: UL1682/1686/50E, CSA C22.2
• Additional Information: Wire Size 10 to 6 AWG; Spring Material Brass with Beryllium Copper
• Catalog Number: ADR3022
• Brand Name: Powertite[R]
• Type: Polarized
• Constructional Feature: Weatherproof
• Voltage Rating: 600 VAC 1-Phase at 50 to 400 Hz, 250 VDC
• Current Rating: 30 Ampere
• Number Of Poles: 2
• Number Of Wires: 2
• Catalog Description: POWERTITE GROUNDING STYLE 1 RECEPTACLE, NUMBER OF POLES: 2, NUMBER OF WIRES: 2, WIRE SIZE: 10 - 6 AWG (BUILDING), 10 - 8 AWG (EXTRA FLEX), AMPERAGE RATING: 30 AMP, VOLTAGE RATING: 600 VAC AT 50 - 400 HZ, 250 VDC, PHASE: 1 PH, MATERIAL: CO
• Category: Pin & Sleeve Devices
• Full Technical Description: Positive Polarization Type; Epoxy Powder Coated Copper-Free Aluminum Material; 2 Wire(S); UL 1682/1686/50E, CSA C22.2 Approval; 600 Volt AC 50/400 Hertz 1-Phase, 250 Volt DC Voltage Rating; 30 Amp Current Rating; 2 Pole(S); Weatherproof, Rain Tight; Spring, Screw Cap; 1, Shell Grounding Style; POWERTITE[TM] Brand; Wire Size 10 to 6 AWG (Building), 10 to 8 AWG (Extra Flexible); Wire Recess Diameter 0.281 Inch; Insulating Block Material Natural Glass Filled Polyester; Spring Material Brass With Beryllium Copper; Enclosure Rating NEMA 3/4/4X; Ambient Temperature Rating -13 to 104 Deg F; Applicable Standard Nec/Cec
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Pin and Sleeve Receptacle
• Unspsc: 39121406
• UPC 12 Digit: 781381186322
• SKU Name: app adr3022
