Voltage Rating: 600 Volt AC 1-Phase at 50 to 400 Hertz, 250 Volt DC
Current Rating: 60 Amp
Number Of Poles: 3
Number Of Wires: 2
Catalog Description: POWERTITE GROUNDING STYLE 2 RECEPTACLE, NUMBER OF POLES: 3, NUMBER OF WIRES: 2, WIRE SIZE: 6 - 2 AWG (BUILDING), 6 - 4 AWG (EXTRA FLEX), AMPERAGE RATING: 60 AMP, VOLTAGE RATING: 600 VAC AT 50 - 400 HZ, 250 VDC, PHASE: 1 PH, MATERIAL: COPP
Category: Pin & Sleeve Devices
Full Technical Description: Positive Polarization Type; Epoxy Powder Coated Copper-Free Aluminum Material; 2 Wire(S); UL 1682/1686/50E, CSA C22.2 Approval; 600 Volt AC 50/400 Hertz 1-Phase, 250 Volt DC Voltage Rating; 60 Amp Current Rating; 3 Pole(S); Weatherproof, Rain Tight; Spring, Screw Cap; 2, Shell, Extra Pole Grounding Style; POWERTITE[TM] Brand; Wire Size 6 to 2 AWG (Building), 6 to 4 AWG (Extra Flexible); Wire Recess Diameter 0.312 Inch; Insulating Block Material Natural Glass Filled Polyester; Spring Material Brass With Beryllium Copper; Enclosure Rating NEMA 3/4/4X; Ambient Temperature Rating -13 to 104 Deg F; Applicable Standard Nec/Cec
