Appleton ALC1050-B Ball Fixture Hanger

Overview

Appleton ALC1050-B Ball Fixture Hanger

Product Specifications

• UPC: 78138114355
• Capacity: 250 LB
• Number Of Hubs: 2
• Hub Location: SIDE, FEED THROUGH
• Material: ZINC ELECTROPLATED DICHROMATE EPOXY POWDER COATED MALLEABLE IRON
• Approval: CSA
• Additional Information: AVAILABLE WITH CONNECTION BLOCK; FLEXIBLE; FOR USE WITH THREADED RIGID METAL CONDUIT AND IMC
• Catalog Number: ALC1050-B
• Brand Name: UNILETS[R]
• Model: ALC
• Type: BALL HANGER
• Fixture Type: FLUORESCENT, HID, INCANDESCENT
• Swing Angle: 20 DEG
• Fixture Stem Size: 1/2 INCH
• Conduit Size: 1 INCH
• Catalog Description: UNILETS ALC SERIES BALL HANGER, SIZE: 1/2 IN STEM, MATERIAL: MALLEABLE IRON WITH STEEL COVER, LAMP TYPE: INCANDESCENT, FLUORESCENT, HID, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER COAT), CONDUIT SIZE: 1 IN, STANDARD: UL FILE NUMBER E109438, FOR USE WITH THREADED RIGID METAL CONDUIT AND IMC
• Category: Lighting Accessories
• Full Technical Description: Ball/Flexible Hanger Type; Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Steel (Cover) Material; 3 Hub(S); UL Approval; 250 Pound Capacity; 1 Inch Conduit Size; Side, Feed-Through Hub Location; LED Fixture Type; 1/2 Inch Fixture Stem Size; 20 Degree Swing Angle; Used on Threaded Imc/Rigid Metal Conduit; Applicable Standard Nec/Cec; ALC Model
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Pendant Fixture Conduit Body Hanger
• Unspsc: 39111817
• UPC 12 Digit: 781381143554
• SKU Name: app alc1050b

Resources

• Manufacturer Spec Sheet
