Additional Information: Contact Material Brass; Enclosure Rating NEMA 3/3R/4/4X
Catalog Number: ARC1044CD
Brand Name: Powertite[TM]
Type: Compressor, Motor Generator Unit, Pump, Welder
Constructional Feature: Rain Tight
Voltage Rating: 600 Volt AC at 50 to 400 Hertz, 250 Volt DC
Current Rating: 100 Amp
Number Of Poles: 4
Number Of Wires: 4
Catalog Description: POWERTITE GROUNDING STYLE 1 CONNECTOR BODY, NUMBER OF POLES: 4, NUMBER OF WIRES: 4, WIRE SIZE: 4 - 1 AWG (BUILDING), 4 - 2 AWG (EXTRA FLEX), AMPERAGE RATING: 100 AMP, VOLTAGE RATING: 600 VAC AT 50 - 400 HZ, 250 VDC, PHASE: 3 PH, MATERIA
Category: Pin & Sleeve Devices
Full Technical Description: Positive Polarization, Circuit Breaking, Compressor, Motor Generator Unit, Pump, Welder, Cellular Relay Station Type; Epoxy Powder Coated Copper-Free Aluminum Material; 0.875 Inch min. Cable Outer Diameter; 1.906 Inch Max. Cable Outer Diameter; 4 Wire(S); UL 1682/1686/50E, CSA C22.2 Approval; 600 Volt AC 50/400 Hertz 3-Phase, 250 Volt DC Voltage Rating; 100 Amp Current Rating; 4 Pole(S); Weatherproof; 1, Shell Grounding Style; POWERTITE[TM] Brand; Wire Recess Diameter 0.391 Inch; Contact Material Copper; Insulating Block Material Fiberglass Reinforced Polyester; Enclosure Rating NEMA 3/4/4X; Applicable Standard Nec/Cec
