Additional Information: Contact Material Copper; Enclosure Rating NEMA 3/3R/4/4X
Catalog Number: ARC3023BC
Brand Name: Powertite[TM]
Type: Compressor, Motor Generator Unit, Pump, Welder
Constructional Feature: Rain Tight
Voltage Rating: 600 Volt AC at 50 to 400 Hertz, 250 Volt DC
Current Rating: 30 Amp
Number Of Poles: 3
Number Of Wires: 2
Catalog Description: POWERTITE GROUNDING STYLE 2 CONNECTOR BODY, NUMBER OF POLES: 3, NUMBER OF WIRES: 2, WIRE SIZE: 10 - 6 AWG (BUILDING), 10 - 8 AWG (EXTRA FLEX), AMPERAGE RATING: 30 AMP, VOLTAGE RATING: 600 VAC AT 50 - 400 HZ, 250 VDC, PHASE: 1 PH, MATERI
Category: Pin & Sleeve Devices
Full Technical Description: Positive Polarization, Circuit Breaking, Compressor, Motor Generator Unit, Pump, Welder, Cellular Relay Station Type; Epoxy Powder Coated Copper-Free Aluminum Material; 0.5 Inch min. Cable Outer Diameter; 1.125 Inch Max. Cable Outer Diameter; 2 Wire(S); UL 1682/1686/50E, CSA C22.2 Approval; 600 Volt AC 50/400 Hertz 3-Phase, 250 Volt DC Voltage Rating; 30 Amp Current Rating; 3 Pole(S); Weatherproof; Shell, Extra Pole, 2 Grounding Style; POWERTITE[TM] Brand; Wire Recess Diameter 0.281 Inch; Contact Material Copper; Insulating Block Material Fiberglass Reinforced Polyester; Enclosure Rating NEMA 3/4/4X; Applicable Standard Nec/Cec
