Appleton BH-503 1/2-13 Tapped Beam Clamp

Overview

Appleton BH-503 1/2-13 Tapped Beam Clamp

Product Specifications

• UPC: 78138115690
• Material: Malleable Iron
• Finish: Hot Dip Galvanized
• Application: Rigid Metal/IMC Conduit, Conduit Hanging System
• Additional Information: Overall Dimension 2.63 Inch Width x 2.25 Inch Height; Approval CSA C22.2, CEC
• Catalog Number: BH-503
• Brand Name: Appleton
• Model: BH
• Type: Wide Throat, Tapped
• Maximum Jaw Capacity: 1.13 Inch
• Supplied With Screw: Yes
• Screw Type: Square Head
• Screw Size: 1/2 Inch-13 TPI
• Catalog Description: BEAM CLAMP, MATERIAL: MALLEABLE IRON, MAXIMUM LOAD: 900 LB, MAXIMUM JAW OPENING: 1.13 IN, FINISH: HOT DIPPED GALVANIZED, LENGTH: 2-1/4 IN, WIDTH: 2.63 IN, SET SCREW: 1/2-13, JAW WIDTH: 1.69 IN, STANDARD: CSA 065178, C22.2 NO. 18.4,, FOR PR
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: Malleable Iron Material; Hot Dip Galvanized Finish; 1.13 Inch Max. Jaw Capacity; Commercial and Industrial, Conduit Hanging System, Ordinary/Hazardous Location Application; 900 Pound Load Capacity; 1/2 Inch-13 TPI Screw Size; Square Head Screw Type; Yes Supplied With Screw; Overall Dimension 2.63 Inch Width X 2.25 Inch Height; Jaw Depth 1.69 Inch; Applicable Standard CEC, CSA C22.2
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Beam Clamp
• Unspsc: 31162905
• UPC 12 Digit: 781381156905
• SKU Name: app bh503
