Appleton BLB150-A 1-1/2" Aluminum LB Mogul Unilet (Body, Cover & Gasket)

Overview

Appleton BLB150-A 1-1/2" Aluminum LB Mogul Unilet (Body, Cover & Gasket)

Product Specifications

• UPC: 78138174328
• Hub Size: 1-1/2 Inch
• Size: 13 Inch Length x 3.13 Inch Width x 5.25 Inch Height
• Installation: Threaded
• Material: Epoxy Powder Coated Copper-Free Aluminum (Body), Neoprene (Gasket), Stainless Steel (Screw)
• Approval: UL 514B, CSA C22.2, NEC, CEC
• Used On: IMC/Rigid Conduit
• Additional Information: Capacity 145 Cubic Inch; Application Pulling of Large and Heavy Conductor, Pulling Straight/45 Degree/90 Degree Angle Turn and/or Making Tap and Splice; Applicable Standard NEMA FB-1
• Catalog Number: BLB150-A
• Brand Name: Appleton
• Model: LB
• Access Opening: Back
• Configuration: LB
• Cover Type: Epoxy Powder Coated Copper-Free Aluminum
• Hub Location: 90 Degree
• Number Of Hubs: 2
• Catalog Description: MOGUL UNILETS TYPE LB NEC 6X CONDUIT OUTLET BODY WITH ASSEMBLED COVER AND GASKET, HUB SIZE: 1-1/2 IN, LENGTH: 13 IN, WIDTH: 3.13 IN, HEIGHT: 5-1/4 IN, MATERIAL: ALUMINUM, FINISH: EPOXY POWDER COAT, CONNECTION: TAPERED FEMALE THREADED, ST
• Category: Aluminum Conduit Bodies & Covers
• Full Technical Description: Epoxy Powder Coated Copper-Free Aluminum (Body), Stainless Steel (Screw) Material; 13 Inch Length X 3.13 Inch Width X 5.25 Inch Height Size; Imc/Threaded Rigid Metal Conduit Used on; 1-1/2 Inch Hub Size; Threaded Installation; lb Configuration; 2 Hub(S); UL 514B, CSA C22.2 Approval; 90 Degree Hub Location; Back Access Opening; UNILETS[R] Brand; Wire Size (3) 3/0 AWG; Capacity 107 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard NEC 6X/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body
• Unspsc: 39131708
• UPC 12 Digit: 781381743280
• SKU Name: app blb150a
