Appleton BT300-M 3" Malleable T Mogul Unilet (Body, Cover & Gasket)

Overview

Appleton BT300-M 3" Malleable T Mogul Unilet (Body, Cover & Gasket)

Product Specifications

• UPC: 78138147421
• Size: 26.88 Inch L x 6 Inch W x 5.94 Inch H
• Installation: Threaded
• Material: Electro Zinc Plated Dichromate Epoxy Powder Coated Malleable Iron Body, Neoprene Gasket, Stainless Steel Screw
• Approval: UL 514B, CSA C22.2, NEC, CEC
• Used On: Rigid Conduit/IMC
• Additional Information: Applicable Standard NEMA FB-1; Capacity 475 Cu Inch; Application Pulling of Large and Heavy Conductor, Pulling Straight/45 Deg/90 Deg Angle Turn and/or Making Tap and Splice
• Catalog Number: BT300-M
• Brand Name: Unilet[R]
• Access Opening: Side
• Configuration: T
• Cover Type: Electro Zinc Plated Dichromate Epoxy Powder Coated Malleable Iron
• Hub Location: Tee
• Number Of Hubs: 3
• Hub Size: 3 Inch
• Catalog Description: MOGUL UNILETS TYPE T NEC 8X CONDUIT OUTLET BODY WITH ASSEMBLED COVER AND GASKET, HUB SIZE: 3 IN, LENGTH: 26.88 IN, WIDTH: 6 IN, HEIGHT: 5.94 IN, MATERIAL: MALLEABLE IRON, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER C
• Category: Steel Conduit Bodies & Covers
• Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Screw) Material; 26.88 Inch Length X 6 Inch Width X 5.94 Inch Height Size; Imc/Threaded Rigid Metal Conduit Used on; 3 Inch Hub Size; Threaded Installation; T Configuration; 3 Hub(S); UL 514B, CSA C22.2 Approval; Tee Hub Location; Side Access Opening; UNILETS[R] Brand; Wire Size (3) 350 MCM; Capacity 475 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard NEC 8X/Cec, NEMA FB-1
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Conduit Body
• Unspsc: 39131708
• UPC 12 Digit: 781381474214
• SKU Name: app bt300m
