Material: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Neoprene (Gasket)
Approval: UL 514B, CSA C22.2
Used On: Rigid Conduit/IMC
Additional Information: Applicable Standard NEC/CEC
Catalog Number: BUB125-M
Access Opening: Back
Configuration: UB
Cover Type: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron
Hub Location: 45 Degree
Number Of Hubs: 2
Hub Size: 1-1/4 Inch
Size: 10.25 Inch L x 2.38 Inch W x 4.13 Inch H
Catalog Description: IMC/RIGID MOGUL CONDUIT BODY, ACCESS OPENING BACK, CONFIGURATION UB, COVER TYPE ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED MALLEABLE IRON, HUB LOCATION 45 DEG, NUMBER OF HUBS 2, HUB SIZE 1-1/4 INCH, SIZE 10.25 INCH L X 2.38 INCH W X 4.13 INCH H, INSTALLATION THREADED, MATERIAL ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED MALLEABLE IRON BODY, NEOPRENE GASKET, STAINLESS STEEL SCREW, FORM TYPE MOGUL, APPROVAL UL 514B/E2527, CSA C22.2, USED ON IMC/RIGID CONDUIT, APPLICABLE STANDARD NEC/CEC, NEMA FB-1, CAPACITY 40 CU INCH
Category: Steel Conduit Bodies & Covers
Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body), Stainless Steel (Screw) Material; 10.25 Inch Length X 2.38 Inch Width X 4.13 Inch Height Size; Imc/Threaded Rigid Metal Conduit Used on; 1-1/4 Inch Hub Size; Threaded Installation; UB Configuration; 2 Hub(S); UL 514B, CSA C22.2 Approval; 45 Degree Hub Location; Back Access Opening; UNILETS[R] Brand; Wire Size (3) 1/0 AWG; Capacity 40 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Industrial, Hazardous Location; Applicable Standard NEC 6X/Cec, NEMA FB-1
