Additional Information: Used On Wiring Devices Such as Switches and Receptacle
Catalog Number: FSWP5-20
Brand Name: Unilet[R]
Model: FS
Device Type: (1) NEMA 5-20P 125 V 20 Ampere 2-Pole 3-Wire Plug
Number Of Gangs: 1
Material: Malleable Iron
Mounting: Device
Approval: CSA C22.2
Catalog Description: PLUG, NUMBER OF POLES: 2, NUMBER OF WIRES: 3, AMPERAGE RATING: 20 AMP, VOLTAGE RATING: 125 V, MATERIAL: BOOT: NEOPRENE, FASTENING RING: ALUMINUM, NEMA RATING: NEMA 5-20P, FOR USE WITH NEMA 5-20R RECEPTACLES
Category: Pin & Sleeve Devices
Full Technical Description: Non-Locking Type; CSA C22.2 Approval; 125 Volt 20 Amp NEMA 5-20R Receptacle, 125 Volt 20 Amp NEMA 5-20P Plug Device Type; Plug Material Neoprene Boot; Number of Poles 2; Number of Wires 3; Includes Aluminum Fastening Ring, Neoprene Gasket, Stainless Steel Screw; Used on Ridge Top Box; Application Commercial/Industrial, Switch and Receptacle; Applicable Standard Nec/Cec
Manufacturer: Appleton Electric
Manufacturer Brand: Appleton Electric
Sub Category: Weatherproof Device Box Cover with Device
