Enclosure: Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III
Material: Zinc Electroplated Dichromate Epoxy Powder Coated Malleable Iron
Approval: UL 886, CSA C22.2
Additional Information: Includes Cover; Application General Purpose Wiring, Pulling of Wires, Connect Conduit Lengths and Change Direction of Conduit Runs, Provide Access for Maintenance
Catalog Number: GRJL75
Brand Name: Unilet[R]
Model: GRJL
Style: L
Hub Size: 3/4 Inch
Hub Type: External
Number Of Hubs: 2
Hub Location: (2) Side
Catalog Description: UNILETS OUTLET BOX, NUMBER OF OUTLET: 2, MATERIAL: MALLEABLE IRON, SIZE: 3/4 IN, CABLE ENTRY: (2) 3/4 IN GRJL HUB, CUBIC CAPACITY: 7.3 CU-IN, KNOCKOUTS: NO, COVER OPENING: 2.13 IN, HEIGHT: 2.88 IN, WIDTH: 2.88 IN, DEPTH: 2.06 IN, FINISH: T
Category: Miscellaneous Conduit Bodies
Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron Material; Round Shape; 3/4 Inch Hub Size; 2 Hub(S); UL 886, CSA C22.2 Approval; Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III Enclosure; Internally Threaded Cover Type; 7.3 Cubic Inch Capacity; L Style; (2) Side Hub Location; External Hub Type; 2.13 Inch Cover Opening Diameter; UNILETS[R] Brand; Constructional Feature Explosionproof/Dust Ignitionproof; Includes Cover, Internal Ground Screw and O-ring; Application General Purpose Wiring, Indoor and Outdoor, Pulling of Wire, Connect Conduit Length and Change Direction of Conduit Run, Provide Access For Maintenance; Applicable Standard Nec/Cec; GRJ Model
