Additional Information: Application General Purpose Wiring, Pulling of Wires, Connect Conduit Lengths and Change Direction of Conduit Runs, Provide Access for Maintenance
Catalog Number: GRL150-A
Brand Name: Unilet[R]
Model: GRL
Style: L
Hub Size: 1-1/2 Inch
Hub Type: External
Number Of Hubs: 2
Hub Location: (2) Side
Catalog Description: UNILETS OUTLET BOX, NUMBER OF OUTLET: 2, MATERIAL: COPPERFREE (4/10 OF 1 PCT MAXIMUM) ALUMINUM, SIZE: 1-1/2 IN, CABLE ENTRY: (2) 1-1/2 IN GRL HUB, CUBIC CAPACITY: 72 CU-IN, KNOCKOUTS: NO, COVER OPENING: 4.88 IN, FORM NUMBER: 3, HEIGHT: 5
Category: Aluminum Conduit Bodies & Covers
Full Technical Description: Epoxy Powder Coated Copper-Free Aluminum Material; Round Shape; 1-1/2 Inch Hub Size; 2 Hub(S); UL, CSA C22.2 Approval; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class 1 Zone 1 and 2 Group Iia Iib, Class III, NEMA 3/4/4X Enclosure; Externally Threaded Cover Type; 72 Cubic Inch Capacity; L Style; (2) Side Hub Location; External Hub Type; 4.88 Inch Cover Opening Diameter; UNILETS[R] Brand; Constructional Feature Explosionproof/Dust Ignitionproof; Ambient Temperature Rating -25 to 40 Deg C; Includes Aluminum Cover, Internal Ground Screw and O-ring; Application General Purpose Wiring, Indoor and Outdoor; Applicable Standard Nec/Cec; GR Model
