Additional Information: Form Type 2; Constructional Feature Explosionproof, Dust-Ignitionproof; Used On Threaded Metal Conduit; Includes Internal Ground Screw and O-Ring; Application Indoor/Outdoor
Catalog Number: GRLB125
Brand Name: UNILETS[R]
Model: GRLB
Style: LB
Hub Size: 1-1/4 Inch
Hub Type: External
Number Of Hubs: 2
Hub Location: Side
Catalog Description: UNILETS OUTLET BOX, NUMBER OF OUTLET: 2, MATERIAL: MALLEABLE IRON, SIZE: 1-1/4 IN, CABLE ENTRY: (2) 1-1/4 IN GRLB HUB, CUBIC CAPACITY: 31 CU-IN, KNOCKOUTS: NO, COVER OPENING: 3.94 IN, FORM NUMBER: 2, HEIGHT: 4-1/2 IN, WIDTH: 4-1/2 IN, DEP
Category: Miscellaneous Conduit Bodies
Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron Material; Round Shape; 1-1/4 Inch Hub Size; 2 Hub(S); UL, CSA C22.2 Approval; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class 1 Zone 1 and 2 Group Iia Iib, Class III Enclosure; Externally Threaded Cover Type; 31 Cubic Inch Capacity; lb Style; (1) Side, (1) Down Hub Location; External Hub Type; 3.94 Inch Cover Opening Diameter; UNILETS[R] Brand; Constructional Feature Explosionproof/Dust Ignitionproof; Ambient Temperature Rating -25 to 40 Deg C; Includes Aluminum Cover, Internal Ground Screw and O-ring; Application General Purpose Wiring, Indoor and Outdoor; Applicable Standard Nec/Cec; GR Model
