Appleton HUB-300 3" Insulated Ko Hub

Appleton HUB-300 3" Insulated Ko Hub

Out of stock

Regular price $79.25 USD
Regular price Sale price $79.25 USD
Sale Sold out
Quantity

Overview

Appleton HUB-300 3" Insulated Ko Hub

Product Specifications

  • UPC: 78138146290
  • Ground Type: Locking Edge of Body
  • Material: Zinc Electroplated Malleable Iron (Body), Neoprene (Gasket)
  • Approval: UL 514B, CSA C22.2
  • Used On: Rigid/IMC
  • Additional Information: Application Suitable for Service Entrance, General Purpose Fitting; Applicable Standard NEMA FB-1
  • Catalog Number: HUB-300
  • Brand Name: Appleton
  • Model: HUB
  • Type: Threaded
  • Throat Type: Insulated
  • Trade Size: 3 Inch
  • Size: 1 Inch Diameter x 2.48 Inch Length
  • Constructional Feature: Flame Resistant
  • Catalog Description: STRAIGHT INSULATED THROAT HUB, SIZE: 3 IN, MATERIAL: MALLEABLE IRON, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER COAT), STANDARD: UL 514B, UL FILE NUMBER E14814, CSA C22.2 NO. 18.3, CSA 065178, NEMA FB-1, UL LISTED F
  • Category: Rigid Conduit Fittings - Steel
  • Full Technical Description: Female Threaded, Straight Type; Zinc Electroplated Ductile Iron (Body), Neoprene (Gasket) Material; 2.48 Inch Length Size; Imc/Rigid Metal Conduit Used on; UL 514B, CSA C22.2 Approval; Bonding Screw; 3 Inch Trade Size; Water Tight, Vibration Resistant; Insulated Throat Type; Hole Diameter 3.52 to 3.64 Inch; Panel Thickness 0.09 to 0.31 Inch; Enclosure Rating Class I Div 2, Class III Div 1 and 2; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard ANSI, Nec/Cec, NEMA FB-1/4/12
  • Manufacturer: Appleton Electric
  • Manufacturer Brand: Appleton Electric
  • Sub Category: Rigid/EMT Conduit Hub
  • Unspsc: 39121311
  • UPC 12 Digit: 781381462907
  • SKU Name: app hub300
