Additional Information: Applicable Standard NEMA FB-1; Application Suitable for Service Entrance, General Purpose Fitting
Catalog Number: HUB-350
Model: HUB
Type: Tapered Threaded
Throat Type: Insulated
Trade Size: 3-1/2 Inch
Size: 4.81 Inch Dia x 3.19 Inch L
Constructional Feature: Flame Resistant
Ground Type: Locking Edge of Body
Catalog Description: RIGID CONDUIT HUB, TYPE TAPERED THREADED, THROAT TYPE INSULATED, TRADE SIZE 3-1/2 INCH, SIZE 4.81 INCH DIA X 3.19 INCH L, CONSTRUCTIONAL FEATURE FLAME RESISTANT, GROUND TYPE LOCKING EDGE OF BODY, MATERIAL ZINC ELECTROPLATED DICHROMATE DIP ALUMINUM POLYMER ENAMELED MALLEABLE IRON BODY, NEOPRENE GASKET, APPROVAL UL, CSA, USED ON RIGID CONDUIT, APPLICATION SUITABLE FOR SERVICE ENTRANCE, GENERAL PURPOSE FITTING
Category: Rigid Conduit Fittings - Steel
Full Technical Description: Female Threaded, Straight Type; Zinc Electroplated Ductile Iron (Body), Neoprene (Gasket) Material; 4.81 Inch Diameter X 3.19 Inch Length Size; Imc/Rigid Metal Conduit Used on; UL 514B, CSA C22.2 Approval; Bonding Screw; 3-1/2 Inch Trade Size; Water Tight, Vibration Resistant; Insulated Throat Type; Hole Diameter 4.02 to 4.13 Inch; Panel Thickness 0.09 to 0.31 Inch; Enclosure Rating Class I Div 2, Class III Div 1 and 2; Application Commercial/Industrial, Hazardous/Wet Location; Applicable Standard ANSI, Nec/Cec, NEMA FB-1/4/12
