Appleton HUB75A 3/4" Aluminum Watertight Hub

Overview

Appleton HUB75A 3/4" Aluminum Watertight Hub

Product Specifications

• UPC: 78138119147
• Approval: UL 514B, CSA C22.2
• Used On: Threadless Rigid Metal Conduit/IMC
• Additional Information: Temperature Rating 302 Deg F
• Catalog Number: HUB75A
• Model: Series HUB
• Type: Threaded
• Throat Type: Polypropylene Insulated
• Trade Size: 3/4 Inch
• Size: 1.67 Inch Dia x 1.49 Inch L
• Constructional Feature: NEMA 2/3/3R/4/4X/5/12/13, Corrosion Resistant, Watertight
• Material: Die Cast Aluminum (Body/Nut), Buna-N (O-Ring)
• Catalog Description: INSULATED HUB, SIZE: 3/4 IN, MATERIAL: ALUMINUM, ENCLOSURE: NEMA 2, 3, 3R, 4, 4X, 5, 12, 13, INSULATION CLASS: 150 DEG C, FINISH: ALUMINUM, CABLE ENTRY: 1.13 IN KNOCK OUT, CONSTRUCTION: RUGGED DIE-CAST, LENGTH: 1.49 IN, HEIGHT: 1.67 IN, ST
• Category: Rigid Conduit Fittings - Aluminum
• Full Technical Description: Tapped Thread Type; Copper-Free Die-Cast Aluminum (Body/Nut), Buna-N (O-ring), Polypropylene (Insulator) Material; 1.67 Inch Diameter X 1.49 Inch Length Size; Imc/Rigid Metal Conduit Used on; UL 514B, CSA C22.2 Approval; 3/4 Inch Trade Size; Corrosion Resistant, Water Tight; Insulated Throat Type; Knockout Hole Size 1.13 Inch; Hole Diameter 1.08 to 1.14 Inch; Panel Thickness 0.03 to 0.25 Inch; Enclosure Rating Class I Div 2, Class II Div 1 and 2, Class III, NEMA 2/3/3R/4/4X/5/12/13; Application Commercial/Industrial, Hazardous/Wet/Dry Location, Indoor/Outdoor; Applicable Standard Nec/Cec
• Manufacturer: Appleton Electric
• Manufacturer Brand: Appleton Electric
• Sub Category: Rigid/EMT Conduit Hub
• Unspsc: 39121311
• UPC 12 Digit: 781381191470
• SKU Name: app hub75a
