Additional Information: Applicable Standard NEMA FB-1; Capacity 230 Cu Inch
Catalog Number: LB789
Brand Name: Unilet[R], FM9[TM]
Access Opening: Back
Configuration: LB
Cover Type: Natural Stamped Copper Free Aluminum
Hub Location: 90 Degree
Number Of Hubs: 2
Hub Size: 2-1/2 Inch
Catalog Description: FM9 UNILETS TYPE LB CONDUIT OUTLET BODY, HUB SIZE: 2-1/2 IN, FORM: 9, LENGTH: 13.94 IN, WIDTH: 5 IN, HEIGHT: 6.63 IN, MATERIAL: ALUMINUM, FINISH: NATURAL ALUMINUM, CONNECTION: TAPERED FEMALE THREADED, STANDARD: UL 514A, UL 514B, UL FILE NUM
Category: Aluminum Conduit Bodies & Covers
Full Technical Description: Natural Copper-Free Aluminum (Body), Stainless Steel (Cover Screw) Material; 5 Inch Width X 6.63 Inch Height Size; Imc/Rigid Conduit Used on; 2-1/2 Inch Hub Size; Threaded Installation; lb Configuration; 2 Hub(S); UL 514A/B, CSA C22.2 Approval; 90 Degree Hub Location; Form 9 Form Type; Back Access Opening; FM9[TM] Brand; Wire Size (3) 300 MCM; Capacity 230 Cubic Inch; Enclosure Rating Class I Div 2; Application Commercial/Residential, Hazardous Location; Applicable Standard Nec/Cec, NEMA FB-1
