Size: 21.06 Inch Length x 5.88 Inch Width x 10 Inch Height
Installation: Threaded
Material: Zinc Electroplated Chromate Epoxy Powder Coated Malleable Iron (Body)
Form Type: Form 35
Approval: UL 514A/B, CSA C22.2, NEC, CEC
Used On: Rigid/IMC Conduit
Additional Information: Includes Cover and Gasket; Application Commercial, Industrial; Applicable Standard NEC/CEC
Catalog Number: LBDN300-M
Brand Name: Appleton
Model: LB
Access Opening: Back
Configuration: LB
Cover Type: Zinc Electroplated Chromate Epoxy Powder Coated Malleable Iron
Hub Location: 90 Degree
Number Of Hubs: 2
Catalog Description: UNILETS TYPE LBDN PULLING FITTING WITH COVER AND GASKET, HUB SIZE: 3 IN, LENGTH: 21.06 IN, WIDTH: 5.88 IN, HEIGHT: 10 IN, MATERIAL: MALLEABLE IRON BODY, NEOPRENE GASKET, FINISH: TRIPLE-COAT (ZINC ELECTROPLATE, CHROMATE AND EPOXY POWDER COAT), CONNECTION: FEMALE THREADED, STANDARD: UL 514B, UL FILE NUMBER E2527, FOR USE WITH RIGID METAL CONDUIT AND IMC
Category: Steel Conduit Bodies & Covers
Full Technical Description: Zinc Electroplated/Chromate/Epoxy Powder Coated Malleable Iron (Body/Cover), Neoprene (Gasket) Material; 21.06 Inch Length X 5.88 Inch Width X 10 Inch Height Size; Imc/Rigid Metal Conduit Used on; Threaded Female/Female Installation; UL 514B, CSA C22.2 Approval; 3 Inch Trade Size; 90 Degree Bend Angle; UNILETS[R] Brand; Wiring Capacity 345 Cubic Inch; Includes Gasket Cover; Application Commercial/Industrial; Applicable Standard Nec/Cec; LBDN Model
