Blackburn ASP20 2/0 Aluminum/Copper Compression Splice

Overview

Blackburn ASP20 2/0 Aluminum/Copper Compression Splice

Product Specifications

• UPC: 78378661066
• Body Material: Seamless Tin Plated High Conductivity Aluminum
• Approval: UL, CSA
• Additional Information: Constructional Feature Corrosion Resistant
• Catalog Number: ASP20
• Model: ASP
• Voltage Rating: 35 Kilovolt
• Conductor Size: 2/0 AWG Stranded
• Conductor Material: Copper/Aluminum
• Color Code: Olive
• Barrel Type: Chamfered
• Length: 2-1/2 Inch
• Catalog Description: TYPE ASP ALUMINUM SPLICE, WIRE SIZE MAX 35KV, WIRE SIZE 2/0 STR, LENGTH 2-1/2 INCH, TIN PLATED, DIE COLOR CODE OLIVE
• Category: Large Terminals & Connectors
• Full Technical Description: 2-1/2 Inch; Copper/Aluminum Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; Seamless Tin Plated High Conductivity Aluminum Body Material; 2/0 AWG Stranded Conductor Size; Olive Color Code; Chamfered Barrel Type; Constructional Feature Corrosion Resistant; ASP Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 783786610662
• SKU Name: asp20 blkbrn
