Blackburn ASP6 6 Aluminum Test Point Splice Sleeve 1-5/8" Gray

Overview

Blackburn ASP6 6 Aluminum Test Point Splice Sleeve 1-5/8" Gray

Product Specifications

• UPC: 78378661063
• Body Material: Seamless Tin Plated High Conductivity Aluminum
• Approval: UL, CSA
• Additional Information: Constructional Feature Corrosion Resistant
• Catalog Number: ASP6
• Model: ASP
• Voltage Rating: 35 Kilovolt
• Conductor Size: 6 AWG Stranded
• Conductor Material: Copper/Aluminum
• Color Code: Gray
• Barrel Type: Chamfered
• Length: 1-5/8 Inch
• Catalog Description: TYPE ASP ALUMINUM SPLICE, MAX 35KV, WIRE SIZE 6 STR, LENGTH 1-5/8 INCH, TIN PLATED, DIE COLOR CODE GRAY
• Category: Large Terminals & Connectors
• Full Technical Description: 1-5/8 Inch; Copper/Aluminum Conductor Material; UL, CSA Approval; 35 Kilovolt Voltage Rating; Seamless Tin Plated High Conductivity Aluminum Body Material; 6 AWG Stranded Conductor Size; Gray Color Code; Chamfered Barrel Type; Constructional Feature Corrosion Resistant; ASP Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Splice
• Unspsc: 39121449
• UPC 12 Digit: 783786610631
• SKU Name: asp6 blkbrn
