B-Line B105GRN 3-Hole Z-Support B22 Channel, Green
Product Specifications
UPC: 78101150052
Process: Hot Rolled Pickled and Oiled
Finish: Dura Green
Thickness: 7/32 Inch
Size: 3.5 inch Length x 1.62 Inch Width x 1.62 Inch Height
Weight: 0.51 Pound
Used On: B22 Channel
Additional Information: Hole Spacing from End Size 13/16 Inch; Hole Spacing on Center Size 1-7/8 Inch
Catalog Number: B105GRN
Type: Z-Support
Channel Depth: 1-5/8 Inch
Channel Width: 1-5/8 Inch
Number Of Holes: 3
Hole Size: 9/16 Inch Diameter
Offset: 1-5/8 Inch
Material: ASTM A1018 Steel
Catalog Description: EATON B-LINE SERIES OFFSET FITTING, 1.62" H X 3.5" L X 1.62" W, STEEL, DURA GREEN, 1/4" GAUGE, FITS CHANNEL TYPE B22
Category: Channel & Strut Fittings
Full Technical Description: Z-Support Type; ASTM A1018 Steel Material; 3.5 Inch Length X 1.62 Inch Width X 1.62 Inch Height Size; Dura Green Finish; B22 Channel Used on; 1-5/8 Inch Channel Width; 7/32 Inch Thickness; Hot Rolled Pickled and Oiled Process; 0.51 Pound Weight; 3 Hole(S); 9/16 Inch Diameter Hole Size; 1-5/8 Inch Channel Depth; 1-5/8 Inch Offset; Hole Spacing From End Size 13/16 Inch; Hole Spacing on Center Size 1-7/8 Inch
