Blackburn CTL1-516 Copper Test Point 1-Hole Lug Short Barrel 1 5/16B Green

Overview

Blackburn CTL1-516 Copper Test Point 1-Hole Lug Short Barrel 1 5/16B Green

Product Specifications

• UPC: 78378613180
• Number Of Pad Holes: 1
• Stud Size: 5/16 Inch
• Color: Green
• Die Index: 37, 94H
• Material: Tin Plated Seamless Copper
• Overall Length: 1-23/32 Inch
• Approval: UL, CSA
• Catalog Number: CTL1-516
• Model: CTL
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 1 AWG Stranded
• Barrel Type: Short, Straight
• Barrel Length: 19/32 Inch
• Pad Size: 7/8 Inch L x 21/32 Inch W x 3/32 Inch Thk
• Catalog Description: COPPER ONE-HOLE LUG, SHORT BARREL, MAX 35KV, 1 STR. WIRE, 5/16 BOLT SIZE, TIN PLATED, DIE COLOR CODE GREEN
• Category: Large Terminals & Connectors
• Full Technical Description: Tin Plated Seamless Copper Material; Green Color; 1-23/32 Inch Overall Length; 19/32 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 1 AWG Stranded Conductor Size; 5/16 Inch Stud Size; 37, 94H Die Index; 7/8 Inch L X 21/32 Inch W X 3/32 Inch Thk Pad Size; 1 Pad Hole(S); Short, Straight Barrel Type; CTL Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Blackburn
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 783786131808
• SKU Name: ctl1516 blkbrn
