Additional Information: Wire Size 6 to 1/0 AWG; Grounding Type Positive
Catalog Number: 4Q-125LT
Brand Name: Ground-Tite[R]
Model: 4Q-L
Type: Straight Male
Throat Type: Insulated with Ground Lug
Trade Size: 1-1/4 Inch
Material: Zinc Electroplated Malleable Iron Body/Nut, Zinc Electroplated Steel Ferrule
Approval: UL 467, CSA C22.2
Catalog Description: OZ-GEDNEY GROUND-TITE TYPE 4Q-LT GROUNDING LIQUID TIGHT STRAIGHT CONNECTOR WITH LUG, SIZE: 1-1/4 IN, CONNECTION: COMPRESSION X TAPERED MNPT HUB, CONDUCTOR RANGE: 6 - 1/0 AWG, MALLEABLE IRON BODY AND NUT, STEEL FERRULE, FINISH: ZINC ELECTROPLATED, NEMA RATING: NEMA 4, INSULATED THROAT, HAZARDOUS LOCATION, 2-7/8 IN WIDTH, 1.938 IN HEIGHT, 1-3/4 IN TURNING RADIUS GLAND NUT, THIRD PARTY CERTIFICATION: UL FILE NUMBER E-24264, CSA 9795, APPLICABLE THIRD PARTY STANDARDS: UL 467, CSA C22.2 NO.41, FEDERAL SPECIFICATION W-F-406E, NEMA : FB-1, CLASS I, DIVISION 2 PER NEC 501.4(B), CLASS I, ZONE 2 PER NEC 505.15(C)(2), CLASS II, DIVISION 1 PER NEC 502.4(A)(1)(E), CLASS II, DIVISION 2 PER NEC 502.4(B)(2), CLASS III, DIVISION 1 PER NEC 503.3(A)(2), CLASS III, DIVISION 2 PER NEC 503.3(B), INTRINSICALLY SAFE PER NEC 504.20, FOR LIQUIDTIGHT FLEXIBLE METAL CONDUIT
Category: Liquid Tight Flex. Conduit Fittings
Full Technical Description: Straight Male Type; Zinc Electroplated Malleable Iron Body/Nut, Zinc Electroplated Steel Ferrule Material; Flexible Metallic Liquidtight Conduit Used on; UL 467, CSA C22.2 Approval; 1-1/4 Inch Trade Size; Insulated With Ground Lug Throat Type; GROUND-TITE[R] Brand; Wire Size 6 to 1/0 AWG; Grounding Type Positive; 4Q-L Model
Manufacturer: O-Z Gedney
Manufacturer Brand: O-Z Gedney
Sub Category: Liquidtight Flexible Conduit Connector
