OZ-Gedney 4Q-200FML 2" Liquidtight Combination Connector

Overview

OZ-Gedney 4Q-200FML 2" Liquidtight Combination Connector

Product Specifications

• UPC: 78312661779
• Additional Information: Size 3-3/16 Inch Dia x 2-3/16 Inch L
• Catalog Number: 4Q-200FML
• Brand Name: Ground-Tite[R]
• Model: 4Q-FML
• Type: Combination
• Trade Size: 2 Inch
• Material: Zinc Plated Malleable Iron Body, Zinc Plated Steel Ferrule
• Approval: UL 467, CSA C22.2
• Used On: IMC/Rigid Conduit/Liquidtight Flexible Metal Conduit
• Catalog Description: OZ-GEDNEY GROUND-TITE TYPE 4Q-FML GROUNDING LIQUIDTIGHT COMBINATION COUPLING, TRADE SIZE: 2 IN, LENGTH: 2-3/16 IN, FLEXIBILITY: RMC AND IMC, MALLEABLE IRON BODY AND NUT, STEEL FERRULE, CONNECTION: FNPT HUB, THIRD PARTY CERTIFICATION: UL FILE NUMBER E-24264, CSA 009795, APPLICABLE THIRD PARTY STANDARDS: UL 467, CSA C22.2 NO. 41, FEDERAL SPECIFICATION W-F-406E, NEMA : FB-1, HAZARDOUS LOCATIONS: CLASS I, DIVISION 2 PER NEC 501.4(B), CLASS I, ZONE 2 PER NEC 505.15(C)(2), CLASS II, DIVISION 1 PER NEC 502.4(A)(1)(E), CLASS II, DIVISION 2 PER NEC 502.4(B)(2), CLASS III, DIVISION 1 PER NEC 503.3(A)(2), CLASS III, DIVISION 2 PER NEC 503.3(B), INTRINSICALLY SAFE PER NEC 504.20, FOR THREADED RIGID CONDUIT AND IMC
• Category: Liquid Tight Flex. Conduit Fittings
• Full Technical Description: Combination Type; Zinc Plated Malleable Iron Body, Zinc Plated Steel Ferrule Material; Imc/Rigid Conduit/Liquidtight Flexible Metal Conduit Used on; UL 467, CSA C22.2 Approval; 2 Inch Trade Size; GROUND-TITE[R] Brand; Size 3-3/16 Inch Dia X 2-3/16 Inch L; 4Q-FML Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Liquidtight Flexible Conduit Connector
• Unspsc: 39131707
• UPC 12 Digit: 783126617795
• SKU Name: ozg 4q200fml

Resources

• Manufacturer Spec Sheet
