Material: ZINC PLATED MALLEABLE IRON BODY, ZINC PLATED STEEL FERRULE
Size: 4-1/8 INCH DIA X 3-1/4 INCH L
Approval: UL 514B, CSA C22.2
Catalog Description: OZ-GEDNEY TYPE 4Q-FM COMBINATION COUPLING, TRADE SIZE: 2-1/2 IN, 4-1/8 IN OUTSIDE DIAMETER, LENGTH: 3-1/4 IN, FLEXIBILITY: RMC AND IMC, MALLEABLE IRON, STEEL FERRULE, CONNECTION: FNPT HUB, ENCLOSURE: NEMA 4, THIRD PARTY CERTIFICATION: UL FILE NUMBER 11853, CSA 009795, APPLICABLE THIRD PARTY STANDARDS: UL 514B, CSA C22.2 NO.18, FEDERAL SPECIFICATION W-F-406E, NEMA : FB-1, HAZARDOUS LOCATIONS: CLASS I, DIVISION 2 PER NEC 501.4(B), CLASS I, ZONE 2 PER NEC 505.15(C)(2), CLASS II, DIVISION 1 PER NEC 502.4(A)(1)(E), CLASS II, DIVISION 2 PER NEC 502.4(B)(2), CLASS III, DIVISION 1 PER NEC 503.3(A)(2), CLASS III, DIVISION 2 PER NEC 503.3(B), INTRINSICALLY SAFE PER NEC 504.20, FOR THREADED RIGID CONDUIT AND IMC
Category: Liquid Tight Flex. Conduit Fittings
Full Technical Description: Zinc Plated Malleable Iron Body, Zinc Plated Steel Ferrule Material; 4-1/8 Inch Dia X 3-1/4 Inch L Size; Rigid Conduit/Imc/Liquidtight Flexible Metal Conduit Used on; Threaded Rigid/Imc to Liquidtight Flexible Metal Conduit Installation; UL 514B, CSA C22.2 Approval; 2-1/2 Inch Trade Size; Liquidtight, Oil Tight, Rain Tight; 4Q-FM Model
Manufacturer: O-Z Gedney
Manufacturer Brand: O-Z Gedney
Sub Category: Rigid/Emt Conduit Combination Coupling
