OZ-Gedney 4Q-438LT 3/8" 45D Insulated Liquidtight Connector

Overview

OZ-Gedney 4Q-438LT 3/8" 45D Insulated Liquidtight Connector

Product Specifications

• UPC: 78312661821
• Used On: FLEXIBLE METALLIC LIQUID TIGHT CONDUIT
• Additional Information: APPLICATION HAZARDOUS LOCATION; ENVIRONMENTAL CONDITIONS OIL TIGHT, RAIN TIGHT; INSTALLATION THREADED
• Catalog Number: 4Q-438LT
• Brand Name: Ground-Tite.
• Model: 4Q-L
• Type: 45 DEG
• Throat Type: INSULATED WITH GROUND LUG
• Trade Size: 3/8 INCH
• Material: MALLEABLE IRON (BODY, , GLAND NUT), ZINC PLATED STEEL FERRULE
• Approval: UL, CSA
• Catalog Description: LIQUIDTIGHT FLEXIBLE CONDUIT CONNECTOR, TYPE 45 DEG MALE, THROAT TYPE INSULATED WITH GROUND LUG, TRADE SIZE 3/8 INCH, MATERIAL ZINC ELECTROPLATED MALLEABLE IRON BODY/NUT, ZINC ELECTROPLATED STEEL FERRULE, APPROVAL UL, CSA, USED ON FLEXIBLE METALLIC LIQUIDTIGHT CONDUIT, WIRE SIZE 14 TO 4 AWG
• Category: Liquid Tight Flex. Conduit Fittings
• Full Technical Description: 45 Deg Type; Malleable Iron (Body, , Gland Nut), Zinc Plated Steel Ferrule Material; Flexible Metallic Liquid Tight Conduit Used on; UL, CSA Approval; 3/8 Inch Trade Size; Insulated With Ground Lug Throat Type; Ground-Tite. Brand; Application Hazardous Location; Environmental Conditions Oil Tight, Rain Tight; Installation Threaded; 4Q-L Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Liquidtight Flexible Conduit Connector
• Unspsc: 39121420
• UPC 12 Digit: 783126618211
• SKU Name: ozg 4q438lt

Resources

• Manufacturer Spec Sheet
