OZ-Gedney BLG-6104 6" Insulated Ground Bushing

Overview

OZ-Gedney BLG-6104 6" Insulated Ground Bushing

Product Specifications

• UPC: 78312604290
• Throat Type: Phenolic Insulated
• Diameter: 7-3/8 Inch
• Height: 1-3/8 Inch
• Material: Zinc Plated Malleable Iron Body, Stainless Steel Screw
• Approval: UL 467/514B, CSA 22.2
• Used On: Rigid Conduit/IMC
• Additional Information: Applicable Standard W-F-408E, NEMA FB-1
• Catalog Number: BLG-6104
• Brand Name: Copper Plus[TM]
• Model: BLG
• Type: Threaded, Set Screw
• Trade Size: 6 Inch
• Wire Size: 14 to 4 AWG Solid/Stranded
• Lug Type: Lay-In
• Conductor Material: Copper
• Catalog Description: CONDUIT HARDWARE, BUSHINGS, INSULATING, TRADE SIZE: 6 INCH, MATERIAL: MALLEABLE IRON OR STEEL/ZINC PLATED, CONNECTION TYPE: SET-SCREW, MAXIMUM TEMPERATURE RATING: 150 DEGREE C, FEATURES: FOR RIGID, IMC, EMT, OUTSIDE DIAMETER: 7 3/8 INCH, WIDTH: 1 3/8 INCH
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: Threaded, Set Screw Type; Zinc Plated Malleable Iron Body, Stainless Steel Screw Material; 1-3/8 Inch; Rigid Conduit/Imc Used on; 14 to 4 AWG Solid/Stranded Wire Size; Copper Conductor Material; UL 467/514B, CSA 22.2 Approval; 7-3/8 Inch Diameter; 6 Inch Trade Size; Phenolic Insulated Throat Type; Lay-in Lug Type; Copper PLUS[TM] Brand; Applicable Standard W-F-408E, NEMA FB-1; BLG Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Grounding Bushing
• Unspsc: 39121312
• UPC 12 Digit: 783126042900
• SKU Name: ozg blg6104
