OZ-Gedney ECGJH-50-8 1/2X8 Flex Coupling

Overview

OZ-Gedney ECGJH-50-8 1/2X8 Flex Coupling

Product Specifications

• UPC: 78312611629
• Approval: UL 886, CSA C22.2
• Additional Information: Includes Insulating Liner; Maximum Temperature Rating 300 Deg F; Constructional Feature Watertight
• Catalog Number: ECGJH-50-8
• Model: ECGJH
• Trade Size: 1/2 Inch
• Fitting Material: Bronze End, Steel Nipple
• Material: Bronze Braid, Brass Tube
• End Type: (2) Threaded Nipple
• Length: 8 Inch
• Enclosure: Class I Div 1 and 2 Group A B C D, Class I Zone 1 and 2 Group IIA IIB IIC, Class II Div 1 and 2 Group E F G, Class III
• Catalog Description: OZ-GEDNEY TYPE ECGJH FLEXIBLE COUPLING, TRADE SIZE: 1/2 IN, 1-13/32 IN OUTSIDE DIAMETER, LENGTH: FLEXIBLE LENGTH: 8 IN, RADIUS: MINIMUM BENDING RADIUS: 10 IN, BRASS TUBE, BRONZE OUTER BRAID WITH INSULATING LINER, CONNECTION: MALE NIPPLE, THIRD
• Category: Rigid Conduit Fittings - Steel
• Full Technical Description: Bronze Braid, Brass Tube Material; 8 Inch; UL 886, CSA C22.2 Approval; Class I Div 1 and 2 Group A B C D, Class I Zone 1 and 2 Group Iia Iib Iic, Class II Div 1 and 2 Group E F G, Class III Enclosure; 1/2 Inch Trade Size; (2) Threaded Nipple End Type; Bronze End, Steel Nipple Fitting Material; Includes Insulating Liner; Maximum Temperature Rating 300 Deg F; Constructional Feature Watertight; ECGJH Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Explosionproof Flexible Conduit Coupling
• Unspsc: 39131707
• UPC 12 Digit: 783126116298
• SKU Name: ozg ecgjh508

Resources

• Manufacturer Spec Sheet
