Enclosure: Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III
Approval: UL, CSA
Additional Information: Overall Dimension 6.25 Inch Length x 3 Inch Width; Used On Threaded IMC/Rigid Metal Conduit; Application Hazardous Location; Applicable Standard NEC/CEC, Mil-F-28675
Catalog Number: EYD-200
Model: EYD
Type: Drain
Turning Radius: 2.31 Inch
Trade Size: 2 Inch
Connection Type: Female/Female
Material: Zinc Electroplated Chromate Epoxy Powder Coated Malleable Iron
Mounting Position: Vertical
Catalog Description: EXPLOSIONPROOF CONDUIT DRAIN AND SEAL FITTING, TYPE DRAIN, TURNING RADIUS 2-5/16 INCH, TRADE SIZE 2 INCH, CONNECTION TYPE FEMALE, FEMALE, MATERIAL ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED DUCTILE/MALLEABLE IRON, MOUNTING POSITION VERTICAL, ENCLOSURE CLASS I DIV 1 AND 2 GROUP B C D, CLASS I ZONE 1 AND 2 GROUP IIA IIB, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, APPROVAL UL 886, CSA C22.2, OVERALL LENGTH 6-1/8 INCH, APPLICATION SEAL CONDUITS IN VERTICAL OR HORIZONTAL, TO MINIMIZE THE PASSAGE OF GASES AND VAPORS AND PREVENT THE PASSAGE OF FLAMES FROM ONE PORTION OF THE ELECTRICAL SYSTEM TO ANOTHER THROUGH THE CONDUIT, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF
Category: Steel Sealing Bodies
Full Technical Description: Drain Type; Zinc Electroplated Chromate Epoxy Powder Coated Malleable Iron Material; Female/Female Connection Type; UL, CSA Approval; Class I Div 1 and 2 Group C D, Class II Div 1 and 2 Group E F G, Class III Enclosure; 2 Inch Trade Size; Vertical Mounting Position; 2.31 Inch Turning Radius; Overall Dimension 6.25 Inch Length X 3 Inch Width; Used on Threaded Imc/Rigid Metal Conduit; Application Hazardous Location; Applicable Standard Nec/Cec, mil-F-28675; EYD Model
