Enclosure: Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III
Approval: UL, CSA C22.2
Additional Information: Includes Removable Male Nipple
Catalog Number: EYDM-75
Brand Name: Unilet[R]
Model: EYDM
Type: Drain
Turning Radius: 1-3/4 Inch
Trade Size: 3/4 Inch
Connection Type: Male Threaded, Female Threaded
Material: Epoxy Powder Coated/Dichromate/Zinc Electroplated Malleable Iron
Catalog Description: EXPLOSIONPROOF CONDUIT DRAIN AND SEAL FITTING, TYPE DRAIN, TURNING RADIUS 1-15/16 INCH, TRADE SIZE 3/4 INCH, CONNECTION TYPE MALE, FEMALE, MATERIAL ZINC ELECTROPLATED CHROMATE EPOXY POWDER COATED DUCTILE/MALLEABLE IRON, MOUNTING POSITION VERTICAL, ENCLOSURE CLASS I DIV 1 AND 2 GROUP B C D, CLASS I ZONE 1 AND 2 GROUP IIA IIB, CLASS II DIV 1 AND 2 GROUP E F G, CLASS III, APPROVAL UL 886, CSA C22.2, OVERALL LENGTH 5-5/32 INCH, APPLICATION SEAL CONDUITS IN VERTICAL OR HORIZONTAL, TO MINIMIZE THE PASSAGE OF GASES AND VAPORS AND PREVENT THE PASSAGE OF FLAMES FROM ONE PORTION OF THE ELECTRICAL SYSTEM TO ANOTHER THROUGH THE CONDUIT, CONSTRUCTIONAL FEATURE EXPLOSIONPROOF
Category: Steel Sealing Bodies
Full Technical Description: Drain Type; Epoxy Powder Coated/Dichromate/Zinc Electroplated Malleable Iron Material; Male Threaded, Female Threaded Connection Type; UL, CSA C22.2 Approval; Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III Enclosure; 3/4 Inch Trade Size; Vertical Mounting Position; 1-3/4 Inch Turning Radius; UNILETS[R] Brand; Includes Removable Male Nipple; EYDM Model
