Additional Information: Application Used to Protect Wires and Cables at Entry and Exit of Conduit; Applicable Standard Federal Specification W-F-408E, NEMA FB-1
Catalog Number: IBC-150
Brand Name: O-Z-Gedney
Model: IBC
Type: Female Threaded
Trade Size: 1-1/2 Inch
Diameter: 2-5/16 Inch
Height: 7/8 Inch
Throat Type: Thermoplastic Insulated
Catalog Description: OZ-GEDNEY TYPE IBC INSULATED BUSHING, SIZE: 1-1/2 IN, MALLEABLE IRON BODY, THERMOPLASTIC INSULATOR, FINISH: ZINC PLATED, CONNECTION: THREADED NPS, 150 DEG C, 2-5/16 IN OUTSIDE DIAMETER, 7/8 IN WIDTH, THIRD PARTY CERTIFICATION: UL FILE NUMBER E-118
Category: Rigid Conduit Fittings - Steel
Full Technical Description: Female Threaded Type; Zinc Plated Malleable Iron Material; 7/8 Inch; Rigid/Imc Conduit Used on; UL 514B, CSA C22.2 Approval; 2-5/16 Inch Diameter; 150 Deg C Temperature Rating; 1-1/2 Inch Trade Size; Thermoplastic Insulated Throat Type; Application Used to Protect Wires and Cables at Entry and Exit of Conduit; Applicable Standard Federal Specification W-F-408E, NEMA FB-1; IBC Model
