OZ-Gedney IBC-150S 1-1/2" Set Screw Insulated Bushing
Product Specifications
UPC: 78312630195
Material: Zinc Plated Malleable Iron
Approval: UL 514B, CSA C22.2
Used On: Rigid Conduit/IMC
Additional Information: Applicable Standard Federal Specification W-F-408E, NEMA FB-1; Application Used to Protect Wires and Cables at Entry and Exit of Conduit
Catalog Number: IBC-150S
Model: IBC-S
Type: Threadless Set Screw
Trade Size: 1-1/2 Inch
Diameter: 2-5/16 Inch
Height: 7/8 Inch
Throat Type: Thermoplastic Insulated
Temperature Rating: 150 Deg C
Catalog Description: CONDUIT HARDWARE, BUSHINGS, INSULATING, TRADE SIZE: 1 1/2 INCH, MATERIAL: MALLEABLE IRON, CONNECTION TYPE: SET-SCREW THREADLESS, MAXIMUM TEMPERATURE RATING: 150 DEGREE C, FEATURES: FOR RIGID AND IMC, OUTSIDE DIAMETER: 2 5/16 INCH, WIDTH: 7/8 INCH
Category: Rigid Conduit Fittings - Steel
Full Technical Description: Threadless Set Screw Type; Zinc Plated Malleable Iron Material; 7/8 Inch; Rigid Conduit/Imc Used on; UL 514B, CSA C22.2 Approval; 2-5/16 Inch Diameter; 150 Deg C Temperature Rating; 1-1/2 Inch Trade Size; Thermoplastic Insulated Throat Type; Applicable Standard Federal Specification W-F-408E, NEMA FB-1; Application Used to Protect Wires and Cables at Entry and Exit of Conduit; IBC-S Model
