OZ-Gedney SR-1009 1" .8-.9 Cord Connector

Overview

OZ-Gedney SR-1009 1" .8-.9 Cord Connector

Product Specifications

• UPC: 78312650800
• Application: Oiltight, Watertight, Strain Relief, Hazardous Location
• Additional Information: Throat Inner Diameter 0.96 Inch; Temperature Rating 90 Deg C
• Catalog Number: SR-1009
• Model: SR
• Type: Straight Male
• Thread Size: 1 Inch
• Material: Zinc Plated Malleable Iron Body, PVC Grommet
• Cord Size: 0.8 to 0.9 Inch
• Size: 1-5/8 Inch Dia x 1-1/4 Inch L
• Approval: UL, CSA
• Catalog Description: OZ-GEDNEY TYPE SR GOLD SEAL STRAIN RELIEF STRAIGHT CONNECTOR, SIZE: 1 IN, CONDUCTOR RANGE: 0.8 - 0.9 IN, MALLEABLE IRON, PVC GROMMETS, FINISH: ZINC PLATED, 90 DEG C, CONNECTION: MNPT, 0.96 IN THROAT INSIDE DIAMETER, 5/8 IN THREAD LENGTH, DIMENSION
• Category: Cable & Cord Grips
• Full Technical Description: Straight Male Type; Zinc Plated Malleable Iron Body, PVC Grommet Material; 1-5/8 Inch Dia X 1-1/4 Inch L Size; UL, CSA Approval; Oiltight, Watertight, Strain Relief, Hazardous Location Application; 1 Inch Thread Size; 0.8 to 0.9 Inch Cord Size; Throat Inner Diameter 0.96 Inch; Temperature Rating 90 Deg C; SR Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Flexible Cord/Cable Connector
• Unspsc: 39121431
• UPC 12 Digit: 783126508000
• SKU Name: ozg sr1009

Resources

• Manufacturer Spec Sheet
