OZ-Gedney SR-755 3/4" .4-.5 Cord Connector

Overview

OZ-Gedney SR-755 3/4" .4-.5 Cord Connector

Product Specifications

• UPC: 78312650755
• Application: Oiltight, Watertight, Strain Relief, Hazardous Location
• Additional Information: Throat Inner Diameter 0.76 Inch; Temperature Rating 90 Deg C
• Catalog Number: SR-755
• Model: SR
• Type: Straight Male
• Thread Size: 3/4 Inch
• Material: Zinc Plated Malleable Iron Body, PVC Grommet
• Cord Size: 0.4 to 0.5 Inch
• Size: 1-3/8 Inch Dia x 1-3/16 Inch L
• Approval: UL, CSA
• Catalog Description: OZ-GEDNEY TYPE SR GOLD SEAL STRAIN RELIEF STRAIGHT CONNECTOR, SIZE: 3/4 IN, CONDUCTOR RANGE: 0.4 - 0.5 IN, MALLEABLE IRON, PVC GROMMETS, FINISH: ZINC PLATED, 90 DEG C, CONNECTION: MNPT, 0.76 IN THROAT INSIDE DIAMETER, 7/16 IN THREAD LENGTH, DIMENSI
• Category: Cable & Cord Grips
• Full Technical Description: Straight Male Type; Zinc Plated Malleable Iron Body, PVC Grommet Material; 1-3/8 Inch Dia X 1-3/16 Inch L Size; UL, CSA Approval; Oiltight, Watertight, Strain Relief, Hazardous Location Application; 3/4 Inch Thread Size; 0.4 to 0.5 Inch Cord Size; Throat Inner Diameter 0.76 Inch; Temperature Rating 90 Deg C; SR Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Flexible Cord/Cable Connector
• Unspsc: 39121431
• UPC 12 Digit: 783126507553
• SKU Name: ozg sr755

Resources

• Manufacturer Spec Sheet
