OZ-Gedney SR-9-504 1/2" .3-.4 Cord Connector

Overview

OZ-Gedney SR-9-504 1/2" .3-.4 Cord Connector

Product Specifications

• UPC: 78312651410
• Application: Oiltight, Watertight, Strain Relief, Hazardous Location
• Additional Information: Throat Inner Diameter 0.5 Inch; Temperature Rating 90 Deg C
• Catalog Number: SR-9-504
• Model: SR9
• Type: 90 Deg Male
• Thread Size: 1/2 Inch
• Material: Zinc Plated Malleable Iron Body, PVC Grommet
• Cord Size: 0.3 to 0.4 Inch
• Size: 1-1/16 Inch Dia
• Approval: UL, CSA
• Catalog Description: OZ-GEDNEY TYPE SR9 GOLD SEAL STRAIN RELIEF 90 DEG CONNECTOR, SIZE: 1/2 IN, CONDUCTOR RANGE: 0.3 - 0.4 IN, MALLEABLE IRON, PVC GROMMETS, FINISH: ZINC PLATED, 90 DEG C, CONNECTION: MNPT, 0.5 IN THROAT INSIDE DIAMETER, 7/16 IN THREAD LENGTH, DIMENSI
• Category: Cable & Cord Grips
• Full Technical Description: 90 Deg Male Type; Zinc Plated Malleable Iron Body, PVC Grommet Material; 1-1/16 Inch Dia Size; UL, CSA Approval; Oiltight, Watertight, Strain Relief, Hazardous Location Application; 1/2 Inch Thread Size; 0.3 to 0.4 Inch Cord Size; Throat Inner Diameter 0.5 Inch; Temperature Rating 90 Deg C; SR9 Model
• Manufacturer: O-Z Gedney
• Manufacturer Brand: O-Z Gedney
• Sub Category: Flexible Cord/Cable Connector
• Unspsc: 39121431
• UPC 12 Digit: 783126514100
• SKU Name: ozg sr9504

Resources

• Manufacturer Spec Sheet
