Additional Information: Includes Inspection Window; Temperature Rating 90 Deg C; ROHS Compliant
Catalog Number: LCA8-10-L
Brand Name: Pan-Lug[TM]
Model: LCA
Voltage Rating: 35 KV
Conductor Material: Copper
Conductor Size: 8 AWG
Barrel Type: Standard with Window, Straight
Barrel Length: 0.56 Inch
Catalog Description: THE LCA8-10-L TIN-PLATED COPPER COMPRESSION LUG, ONE-HOLE, STANDARD BARREL, HAS COLOR-CODED BARRELS MARKED WITH PANDUIT AND SPECIFIED COMPETITOR DIE INDEX NUMBERS FOR PROPER CRIMP DIE SELECTION. AN INSPECTION WINDOW AIDS TO VISUALLY ASSURE FULL CONDUCTOR INSERTION, AND THE TIN-PLATE MATERIAL HELPS TO INHIBIT CORROSION. UL LISTED AND CSA CERTIFIED TO 35 KV AND TEMPERATURE RATED TO 90C.
Category: Large Terminals & Connectors
Full Technical Description: Electro Tin Plated Copper Material; Red Color; 1.25 Inch Overall Length; 0.56 Inch Barrel Length; Copper Conductor Material; UL 486A/486B, CSA C22.2 Approval; 35 kV Voltage Rating; 8 AWG Conductor Size; #10 Stud Size; P21, 49 (Burndy), 21 (T and B) Die Index; 0.41 Inch W X 0.08 Inch Thk Pad Size; 1 Pad Hole(S); Standard With Window, Straight Barrel Type; Pan-LUG[TM] Brand; Includes Inspection Window; Temperature Rating 90 Deg C; RoHS Compliant; LCA Model
