Panduit LCCF500-12-6 Copper Lug 2-Hole 500Kcmil Flared 1/2 Stud Pkg 6

Overview

Panduit LCCF500-12-6 Copper Lug 2-Hole 500Kcmil Flared 1/2 Stud Pkg 6

Product Specifications

• UPC: 07498375320
• Pad Hole Spacing: 1.75 Inch
• Stud Size: 1/2 Inch
• Color: Pink
• Die Index: P99
• Material: Electro Tin Plated Copper
• Overall Length: 7.04 Inch
• Approval: UL, CSA
• Additional Information: RoHS Compliant; Wire Strip Length 2-15/16 Inch; Temperature Rating 90 Deg C
• Catalog Number: LCCF500-12-6
• Voltage Rating: 35 KV
• Conductor Material: Copper
• Conductor Size: 500 KCMIL (Flex Class K/M), 535.3 KCMIL (Flex Diesel Locomotive)
• Barrel Type: Belled, Long, Straight
• Barrel Length: 2.88 Inch
• Pad Size: 1.89 Inch W x 0.26 Inch Thk
• Number Of Pad Holes: 2
• Catalog Description: TWO-HOLE, LONG FLARED BARREL, 500 KCMIL CABLE, 1/2 BOLT HOLES, 1.75 HOLE SPACING, NEMA HOLE SIZES AND SPACING.
• Category: Large Terminals & Connectors
• Full Technical Description: Electro Tin Plated Copper Material; Pink Color; 7.04 Inch Overall Length; 2.88 Inch Barrel Length; Copper Conductor Material; UL, CSA Approval; 35 kV Voltage Rating; 500 kcmil (Flex Class K/M), 535.3 kcmil (Flex Diesel Locomotive) Conductor Size; 1/2 Inch Stud Size; P99 Die Index; 1.89 Inch W X 0.26 Inch Thk Pad Size; 2 Pad Hole(S); 1.75 Inch Pad Hole Spacing; Belled, Long, Straight Barrel Type; Pan-LUG[TM] Brand; RoHS Compliant; Wire Strip Length 2-15/16 Inch; Temperature Rating 90 Deg C
• Manufacturer: PANDUIT CORPORATION
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 074983753208
• SKU Name: pand lccf500126
