T&B 54112UB 4/0Awg Purple 90D Copper Lug

Overview

T&B 54112UB 4/0Awg Purple 90D Copper Lug

Product Specifications

• UPC: 78621086963
• Stud Size: 3/8 Inch
• Color: Purple
• Die Index: 54
• Material: Electro Tin Plated Wrought Copper
• Overall Length: 1.63 Inch
• Approval: UL, CSA
• Catalog Number: 54112 UB
• Model: 541
• Voltage Rating: 600 V to 35 KV
• Conductor Material: Copper
• Conductor Size: 4/0 AWG (Code), 3/0 AWG (Weld, Flex), 450/24 (Flex), 200 (Navy, Flex), 703/0.0154 (Flex)
• Barrel Type: 90 Deg Standard
• Pad Size: 0.93 Inch L x 1.03 Inch W x 0.14 Inch Thk
• Number Of Pad Holes: 1
• Catalog Description: COPPER ONE-HOLE LUG, 90 DEGREE BEND STANDARD BARREL, PEEP HOLE, MAX 35KV, WIRE SIZE 4/0 AWG, 3/8 INCH BOLT SIZE, 3/8 INCH HOLE SPACING, TIN PLATED, DIE CODE 54, DIE COLOR CODE PURPLE 54
• Category: Large Terminals & Connectors
• Full Technical Description: Electro Tin Plated Wrought Copper Material; Purple Color; 1.63 Inch Overall Length; Copper Conductor Material; UL, CSA Approval; 600 V to 35 kV Voltage Rating; 4/0 AWG (Code), 3/0 AWG (Weld, Flex), 450/24 (Flex), 200 (Navy, Flex), 703/0.0154 (Flex) Conductor Size; 3/8 Inch Stud Size; 54 Die Index; 0.93 Inch L X 1.03 Inch W X 0.14 Inch Thk Pad Size; 1 Pad Hole(S); 90 Deg Standard Barrel Type; 541 Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 786210869636
• SKU Name: t&b 54112ub
