T&B 54947BE 1-Hole Long Barrel 5/16 Hole No1

Overview

T&B 54947BE 1-Hole Long Barrel 5/16 Hole No1

Product Specifications

• UPC: 78621089012
• Number Of Pad Holes: 1
• Stud Size: 5/16 Inch
• Color: Green
• Die Index: 37
• Material: Electro Tin Plated Wrought Copper
• Overall Length: 2.18 Inch
• Approval: UL, CSA
• Additional Information: Includes Blind End Inspection Hole
• Catalog Number: 54947BE
• Brand Name: Color-Keyed
• Model: 549
• Voltage Rating: 600 Volt to 35 Kilovolt
• Conductor Material: Copper
• Conductor Size: 1 AWG (Code), 60.5 KCMIL (Flex), 150/24 (Flex)
• Barrel Type: Long, Straight
• Pad Size: 0.88 Inch Length x 0.68 Inch Width x 0.11 Inch Thickness
• Catalog Description: COPPER ONE-HOLE LUG, LONG BARREL, BLIND END, MAX 35KV, WIRE SIZE #1 AWG, 5/16 INCH BOLT SIZE, TIN PLATED, DIE CODE 37, DIE COLOR CODE GREEN
• Category: Large Terminals & Connectors
• Full Technical Description: Electro Tin Plated Wrought Copper Material; Green Color; 2.18 Inch Overall Length; Copper Conductor Material; UL, CSA Approval; 600 Volt to 35 Kilovolt Voltage Rating; 1 AWG (Code), 60.5 kcmil (Flex), 150/24 (Flex) Conductor Size; 5/16 Inch Stud Size; 37 Die Index; 0.88 Inch Length X 0.68 Inch Width X 0.11 Inch Thickness Pad Size; 1 Pad Hole(S); Long, Straight Barrel Type; Includes Blind End Inspection Hole; 549 Model
• Manufacturer: THOMAS & BETTS
• Manufacturer Brand: T&B Corp.
• Sub Category: Compression Cable Lug
• Unspsc: 39121405
• UPC 12 Digit: 786210890128
• SKU Name: t&b 54947be
