T&B 570F 1-1/2" Cast Cover, Gray Iron, Form 7

Overview

T&B 570F 1-1/2" Cast Cover, Gray Iron, Form 7

Product Specifications

• UPC: 78621092413
• Catalog Number: 570F
• Type: Screw, Oval
• Trade Size: 1-1/2 Inch
• Form Type: Form 7
• Material: Zinc Plated Aluminum Acrylic Coated Sand Cast Gray Iron Cover
• Approval: UL 514A/B, CSA C22.2
• Additional Information: Includes Stainless Steel Screw and Neoprene Gasket; Used On EMT Conduit; Applicable Standard Federal Specification S W-C 586D
• Catalog Description: FORM 7, 1-1/2 INCH GRAY IRON CONDUIT BODY COVER AND NEOPRENE GASKET
• Category: Steel Conduit Bodies & Covers
• Full Technical Description: Screw, Oval Type; Zinc Plated Aluminum Acrylic Coated Sand Cast Gray Iron Cover Material; UL 514A/B, CSA C22.2 Approval; 1-1/2 Inch Trade Size; Form 7 Form Type; Includes Stainless Steel Screw and Neoprene Gasket; Used on EMT Conduit; Applicable Standard Federal Specification S W-C 586D
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Conduit Body Cover
• Unspsc: 39121304
• UPC 12 Digit: 786210924137
• SKU Name: t&b 570f

Resources

• Manufacturer Spec Sheet
