T&B LBY15-TB 1/2" Capped Elbow, Iron, Female/Female, Explosion-Proof

Overview

T&B LBY15-TB 1/2" Capped Elbow, Iron, Female/Female, Explosion-Proof

Product Specifications

• UPC: 78621068914
• Approval: UL
• Additional Information: Constructional Feature Explosionproof, Dust Ignitionproof, Rain Tight; Cap Size 5 Inch Diameter; Throat Size 0.57 to 0.61 Inch; Enclosure Rating Class I Div 1 and 2 Group C D, Class II Div 1 Group F G, Class III Div 1 and 2, NEMA 3/4/7CD/9E/9F/9G; Install
• Catalog Number: LBY15-TB
• Brand Name: T&B
• Model: LB
• Type: Capped
• Trade Size: 1/2 Inch
• Bend Angle: 90 Degree
• Connection Type: Female, Female
• Material: Ductile Iron
• Catalog Description: 1/2 INCH HAZARDOUS LOCATION CAPPED ELBOW, DUCTILE IRON
• Category: Steel Sealing Bodies
• Full Technical Description: Capped Type; Ductile Iron Material; Female, Female Connection Type; UL Approval; 1/2 Inch Trade Size; 90 Degree Bend Angle; Constructional Feature Explosionproof, Dust Ignitionproof, Rain Tight; Cap Size 5 Inch Diameter; Throat Size 0.57 to 0.61 Inch; Enclosure Rating Class I Div 1 and 2 Group C D, Class II Div 1 Group F G, Class III Div 1 and 2, NEMA 3/4/7CD/9E/9F/9G; Installation Screw-on; Application Hazardous, Wet Location; LB Model
• Manufacturer: ABB, Inc. - Thomas & Betts
• Manufacturer Brand: T&B Corp.
• Sub Category: Explosionproof Conduit Elbow
• Unspsc: 39131717
• UPC 12 Digit: 786210689142
• SKU Name: t&b lby15tb

Resources

• Manufacturer Spec Sheet
